Linear Pool Clip
Vinyl Liner Pool
Assess the shape of the pool and determine whether you will need to bend the coping around corners or create 90° corners.
a) Bending the coping
b) Creating 90° corners
Insert the coping into the liner track. Modern Moudling's pool coping is designed to wedge into the liner track, eliminating the need for two-way tape or tie-wire. This innovative design also ensures a secure fit and no debris to clean out of the track after the pour.
Insert the reuasable clips along the line and push them into the liner track. Rotate the clip 90° to lock it in. When you get to a joint, insert a clip and rotate it 45° to cover both forms and ensure maximum support. For best results, clips should be 10-12" apart around the curves and 8-10" apart where the pool is straight.
Ready to pour! Remember to spray the forms with form release or cooking oil and remove all bending tape prior to pouring.
Pour the concrete away from the coping and rake or shovel it into the coping form. Using a vibrating tool, vibrate around the coping for a smooth finish.
Stripping the forms
Before the concrete has fully cured, unlock the clips and remove the coping forms. Using a damp sponge, smooth out the joints and edges.
